Specifications:

• Service range: Vertical travel to 36”
• Platform lowered height 1 ½”
• Platform usable size: 32” wide x 52” long
• Lift controls mounted in power unit shroud constant pressure push button
• Weather tight power unit, controls and electrical components
• Key lock-out controls
• Rated load capacity: 750 lbs.
• Industrial 2 HP DC motor
• Power supply required: 110V AC Single Phase
• 12V DC operation (lift runs independent of AC power)
• 12V DC also provides backup operation in case of power failure
• Battery charge indicator gauge
• Drive system: electric hydraulic with dual hydraulic actuators
• Safety internal brass velocity fuse (prevents platform from dropping in case of hydraulic failure)
• Aluminum pump and manifold with integrated hydraulic valves
• Adjustable upward travel limit switch
• Minimum 42” high guards with mid-rails and 8” solid kick plates on both sides
• Automatic “flip-up” ramp/run-off guard on platform entrance 12” ramp
• 2 inch/second lift speed
• Maintenance supports
• Self lubricating bearings on all rollers and pivot points
• Heavy duty steel construction
• Enamel paint with ultraviolet protection finish
• Non-slip platform surface
• Cold temperature synthetic hydraulic fluid (-15 Degrees F to 120 Degrees F)

ADA Compliant Options:

• Under platform safety
• Enclosed sides & handrails
• Gates with interlock
• Solid steel shroud surrounding lift

Platform Overall: 32"W x 50"L

Capacity: 750 lbs.

Raised Height: 36"

Net Weight: 785 lbs.
