Specifications

MODELS

DPL-35S

MEASUREMENTS

US

Working height

40 ft 10 in

Platform height

34 ft 10 in

Height – stowed

6 ft 6 in

Length – stowed

6 ft 10 in

Width

2 ft 7.5 in

PRODUCTIVITY

Lift capacity:

ANSI

CE

CSA

600 lbs

600 lbs

500 lbs

ANSI

Outright footprint:

A. Length

7 ft 2 in

B. Width

5 ft 8 in

C. Corner access

2 ft

D. Wall Access front

9 in

E. Wall Access side

1 ft 10 in

CSA

Outright footprint:

A. Length

7 ft 9 in

B. Width

7 ft 2 in

C. Corner access

2 ft 10 in

D. Wall Access front

1 ft 1 in

E. Wall Access side

2 ft 7 in

CE

Outright footprint:

A. Length

7 ft 2.25 in

B. Width

5 ft 8.75 in

C. Corner access

2 ft

D. Wall Access front

9 in

E. Wall Access side

1 ft 10 in

Platform length

6 ft

Platform width

2 ft 3.5 in

POWER

Power source:

AC models

DC models

110 V / 50-60 Hz or 220 V / 50-60 Hz

12 V

WEIGHT

ANSI (AC)

1,574 lbs

ANSI (DC)

1,684 lbs

CE (AC)

1,645 lbs

CE (DC)

1,755 lbs

CSA (AC)

1,745 lbs

CSA (DC)

1,789 lbs

STANDARDS COMPLIANCE

ANSI A92.3, CSA B354.1, CE Compliance, AS 1418.10

Features

Easily Configured to Meet you Needs

PLATFORM

6 ft x 2 x 3.5 in (1.83 m x .70 m)

POWER OPTIONS

AC power 110V / 50-60 Hz

AC power 220V / 50-60 Hz

DC power 12V / 190 amp battery

Standard Features

MEASURMENTS

DPL-35S

40 ft 10 in (12.62 m) working height

34 ft 10 in (10.62 m) platform height

2 ft 7.5 in (.80 m) base width

500-600 lb (227-272 kg) lift capacity

PRODUCTIVITY

Large platform with room for 1-2 workers

Auxiliary platform lowering

Most rigid mast in the industry

Durable base system

Easily rolls through standard doorways

AC power to platform

Dual activated up/down switch

Ground fault interrupt lower receptacle

Patented outrigger interlock system

Outrigger storage socks

Swivel-lock caster

Tie down attachment points

Forklift pocket access on all sides

Angled entry ladder

LED lights confirm proper set-up of outriggers

Winch attachment points

Locking key switch

POWER

DC models include a 15 amp charging system with 110V / 50-60 Hz or 220V / 50-60 Hz input voltage
