We are your source for Telescopic Booms.
Genie Lift - 4 WD - With Jib
Item Details
Genie Lift - 4 WD - With Jib
Item Name:
Genie Lift - 4 WD - With Jib
Item #:
GEN-S-85WJIB4WD
Average Rating:

Product Image Gallery:

Set up fees may apply, please contact us for details.

SPECIFICATIONS



MODEL

S-85

MEASUREMENTS

US

Working height maximum

91 ft

Platform height maximum

85 ft

Horizontal reach maximum

76 ft 6 ft

Below ground reach

9 ft 6 in

A. Platform length – 8 ft model

     Platform length – 6 ft model

3 ft

2 ft 6 in

B. Platform width – 8 ft model

     Platform width – 6 ft model

8 ft

6 ft

C. Height – stowed

9 ft 2 in

D. Length – stowed

     Length – transport (jib tucked under)

40 ft

38 ft

E. Width

8 ft 2 in

F. Wheelbase

9 ft 4 in

G. Ground clearance - center

13 in

PRODUCTIVITY



Lift capacity – 8 ft platform

Lift capacity – 6 ft platform

500 lbs

500 lbs

Platform rotation

160 degrees

Vertical jib rotation

135 degrees

Turntable rotation

360 degree continuous

Turntable tailswing

4 ft 8 in

Drive speed – stowed – 2WD/4WD

Drive speed – raised/extended

3.5 mph

0.68 mph

Gradeability – 2WD – stowed

Gradeability – 4WD - stowed

30%

45%

Turning radius – axle extended: inside

                                                   outside

12 ft

21 ft 6 in

Controls

12V DC proportional

Tires – RT lug

Foam filled 18-625, 16 ply

POWER



Power source

Deutz TD 2011 L04i 4-cylinder turbocharged diesel, 74 hp (55 kW)

Perkins 804D-33 4-cylinder diesel, 63 hp (47 kW)

Continental TME27 4 cylinder Gasoline/LPG 74 hp (55 kW)

Auxiliary power unit

12V DC

Hydraulic tank capacity

40 gal

Fuel tank capacity – diesel

35 gal

Fuel tank capacity – gas/LPG

30 gal

WEIGHT



2WD

37,900 lbs

4WD

38,000 lbs

STANDARDS COMPLIANCE:

ANSI A92.5, CSA B354.4, CE Compliance

FEATURES

EASILY CONFIGURED TO MEET YOUR NEEDS

PLATFORM

Steel 8 ft (2.44 m)

Steel 6 ft (1.83 m)

Steel 6 or 8 ft (1.83 or 2.44 m) tri-entry

Steel 4 ft (1.22 m)

Steel 5 ft (1.52 m)

JIB OPTIONS

Non-jib

5 ft (1.52 m) jib boom

POWER

Deutz turbocharged diesel 74 hp (55 kW)

Perkins diesel 63 hp (47 kW)

Continental Gas/LPG 74 hp (55 kW)

DRIVE

2WD

4WD

AXLE

Fixed width with active oscillation

TIRE

Rough terrain foam-filled (standard)

Rough terrain non-marking foam-filled

High floatation air-filled (Increases width by 4 in)

STANDARD FEATURES

MEASUREMENTS

S-85

91 ft (27.90 m) working height

76 ft 6 in (23.3 m) horizontal reach

500 lb (227 kg) lift capacity

PRODUCTIVITY

Self-leveling platform

Hydraulic platform rotation

Fully proportional Hall effect joystick controls

Drive enable

AC power cord to platform

Horn

Hour meter

Tilt alarm

Descent alarm

360 degree continuous turntable rotation

Locking low profile turntable covers

Positive traction drive

Two speed wheel motors

POWER

All engines are emissions compliant

12 V DC auxiliary power

Anti-restart engine protection

Auto engine fault shutdown

Catalytic converter muffler (Continental engine only)

Engine block heater (Continental engine only)

Item Options
750 lb capacity, S-80 only
S-80-1 (Add $2,868.00)
8 ft. tri-entry steel platform
S-80-2 (Add $595.00)
Aircraft protection (includes platform foam padding & padded disable system)
S-80-3 (Add $7,025.00)
Platform swing gate
S-80-4 (Add $630.00)
6 ft. or 8 ft. platform 1/2 height mesh inserts with gate
S-80-5 (Add $464.00)
Air line to platform, 1/2 in. inner diameter
S-80-6 (Add $805.00)
Platform auxiliary top rail
S-80-7 (Add $493.00)
Hydraulic oil cooler
S-80-8 (Add $774.00)
Biodegradable hydraulic fluid
S-80-9 (Add $2,387.00)
Fire resisitant hydraulic fluid
S-10-10 (Add $3,844.00)
Basic hostile environment kit (cylinder bellows, boom wiper seals, platform and ground control box cover)
S-10-11 (Add $4,215.00)
Deluxe hostile environment kit (Basic hostile environment kit plus: ring gear guard, air pre-cleaner)
S-11-12 (Add $5,475.00)
Diesel scrubber muffler with spark arrestor (Diesel only, standard on Continental)
S-11-13 (Add $3,685.00)
Intake air pre-cleaner
S-11-14 (Add $580.00)
AC generator (110V/60Hz, 3000W or 220V/50Hz, 2500W)
S-11-15 (Add $2,850.00)
Welder leads to platform
S-11-16 (Add $1,006.00)
Welder Ready package (includes hydraulic oil cooler)
S-11-17 (Add $5,752.00)
ArcPro 275 heavy duty welder package (includes hydraulic oil cooler)
S-11-18 (Add $8,191.00)
Engine gauge package (oil pressure, temp & amp)
S-11-19 (Add $400.00)
Second battery
S-11-20 (Add $670.00)
Tow package
S-11-21 (Add $3,715.00)
LP only (Continental engine only)
S-11-22
Continental or Perkins (5W-40 Syn engine oil, freeze plug heater & 110V battery blanket, platform control board heater & oversized foot switch cover
S-11-23 (Add $250.00)
Deutz (5W-40 Syn engine oil, oil pan heater & 110V battery blanket) platform control board heater, & oversized foot switch cover
S-11-24 (Add $250.00)
Rough terrain, non-marking, foam-filled tires
S-11-25 (Add $1,655.00)
High floatation tires
S-11-26 (Add $5,845.00)
Alarm package (includes flashing beacons, motion and travel alarm)
S-11-27 (Add $475.00)
Lockable platform control box covers
S-11-28 (Add $355.00)
Tool tray
S-11-29 (Add $255.00)
Panel cradle package (requires tri-entry platform)
S-11-30 (Add $785.00)
Platform work lights (includes two 12V 36W lights)
S-11-31 (Add $915.00)
LP tank, 33.5 lb (Continental engine only)
S-80-32 (Add $510.00)
